UNS N06690 seamless pipe for Nuclear Power Industry

UNS N06690 seamless pipe for Nuclear Power Industry

UNS N06690 seamless pipe for Nuclear Power Industry

Product Details:

Place of Origin: Suzhou, China
Brand Name: AIWEN
Certification: BV, TUV, , ISO, PED
Model Number: UNS N06690

Payment & Shipping Terms:

Minimum Order Quantity: 1 Metric Ton
Price: Available per request
Packaging Details: Wooden crate
Delivery Time: 60 days
Payment Terms: T/T
Supply Ability: 50 Metric Ton per month
Contact Now
Detailed Product Description
Out Diameter: 10-20mm Wall Thickness: 1-2mm



Inconel 690 /UNS N06690/W. Nr. 2.4642 U shape seamless pipe for Nuclear Power Industry

General introduction

Inconel 690  (UNS N06690/W. Nr. 2.4642) is a high-chromium nickel alloy with excellent resistance to many corrosive aqueous media and hightemperature atmospheres. In addition to its corrosion resistance, Inconel 690 has high strength, good metallurgical stability, and favorable fabrication characteristics.



The substantial chromium content gives the alloy outstanding resistance to oxidizing chemicals and to high-temperature oxidizing gases.



The high level of nickel imparts resistance to stresscorrosion cracking in chloride-containing environments as well as to sodium hydroxide solutions. The properties of Inconle 690 are useful for various applications involving nitric or nitric/hydrofluoric acid solutions. Examples are tail-gas reheaters used in nitric acid production and heating coils and tanks for nitric/hydrofluoric solutions used in pickling of stainless steels and reprocessing of nuclear fuels.



The alloy’s resistance to sulfur-containing gases makes it an attractive material for such applications as coal-gasification units, burners and ducts for processing sulfuric acid, furnaces for petrochemical processing, recuperators, incinerators, and glass vitrification equipment for radioactive waste disposal.



In various types of high-temperature water, alloy 690 displays low corrosion rates and excellent resistance to stress-corrosion cracking. Thus, alloy 690 is widely used for steam generator tubes, baffles, tubesheets, and hardware in nuclear power generation.



Chemical compostion

Element Content (%)
Chromium, Cr 27-31
Iron, Fe 7-11
Silicon, Si 0.5 max
Manganese, Mn 0.5 max
Copper, Cu 0.5 max
Silicon, Si 0.5 max
Carbon, C 0.05 max
Sulfur, S 0.015 max
Nickel, Ni Balance





Physical property

Properties Metric Imperial
Density 8.19 g/cm³ 0.296 lb/in³
Melting point 1343-1377°C 2450-2510°F



Applications

  • Duct work
  • High temperature burners
  • Furnaces
  • Petrochemical heaters
  • Nuclear power

Dimension

O.D.: 10-20mm

Wall thickness: 1-2mm

Length: 3-6 meter



Finish

Black or bright finish
