Permanent-magnet alloy P6 alloy(USA Standard)_2J4 China Standard GB/T 14988-1994

Product Details:

Place of Origin:	Suzhou, China
Brand Name:	AIWEN
Certification:	ISO
Model Number:	P6 alloy

Payment & Shipping Terms:

Minimum Order Quantity:	50kg
Price:	Available per request
Packaging Details:	Wooden case, carton or per customer requirements
Delivery Time:	30 days
Payment Terms:	T/T
Supply Ability:	10000 kg per month

Contact Now

Detailed Product Description

Type:	Permanent	Composite:	Ferrite Magnet
Shape:	Strip	Application:	Industrial Magnet

Permanent-magnet alloy P6 Alloy(USA Standard)_2J4 China Standard GB/T 14988-1994
P6 alloy is a cobalt base precipitation hardened alloy, similar to Vicalloy, which combines the advantages of high hysteresis loss and low magnetizing force into one material.
It exhibits the highest efficiency (loss per unit magnetizing force) of any known material. P6 alloy has been used for hysteresis motor applications because of this feature.
Density:8.16
Application
Ductile Magnetic alloys have been used for biasing magnets in meters and magnetic actuators, as magnetic coded devices, field coils for DC motors and servos, and hysteresis motor laminations.

Type	Grade	Relative Grade	Standard
Deformation Fe-Cr-Co Permanent Magnetic Alloy	2J83	-	YB/T5261-1993
	2J84	CKSR400Japan
	2J85	CKSR500Japan
Magnetic Hysteresis Alloy	2J4	P6 alloyU.S.A.	GB/T14988-1994 Cold-Rolled Strips For Hysteresis Alloys
	2J7	52Russia
	2J9	529Russia
	2J10	Vicalloy IU.S.A.
	2J11	5211Russia
	2J12	5212Russia
	2J51	1214Russia
	2J52	16Russia
	2J53	12Russia

Grade and Chemical Composition (see Table 1)
Table 1 Grade and Chemical Composition

Grade	Chemical Composition (%)
	C	Si	P	S	Mn	Co	V	Ni	Mo	W	Fe
	≤				Mn	Co	V	Ni	Mo	W	Fe
2J4	0.12	0.70	0.025	0.020	≤0.70	44~46	3.50~4.50	5.30~ 6.70			Balance
2J7	0.12	0.70	0.025	0.020	≤0.70	51~53	6.50~7.50	≤0.70			Balance
2J9	0.12	0.70	0.025	0.020	≤0.70	51~53	8.50~9.50	≤0.70			Balance
2J10	0.12	0.70	0.025	0.020	≤0.70	51~53	9.50~10.5	≤0.70			Balance
2J11	0.12	0.70	0.025	0.020	≤0.70	51~53	10.5~11.5	≤0.70			Balance
2J12	0.12	0.70	0.025	0.020	≤0.70	51~53	11.5~12.5	≤0.70			Balance
2J51	0.03	0.50	0.030	0.030	≤0.70	11.0~13.0				14.0~15.0	Balance
2J52	0.03	0.50	0.030	0.030	≤0.70	15.0~17.0			5.00~6.00	10.0~11.0	Balance
2J53	0.03	0.50	0.030	0.030	11.5~ 12.5			3.00~ 4.00	2.50~ 3.50		Balance

Note: Molybdenum can be substituted by 1.30-1.70% vanadium for 2J53 alloy.
Specification: Sheet/Plate, Bar/Rod
Tianjin Huaan International Trade Co., Ltd is a professional supplier of stainless steel, high temperature alloy, anti-corrosion alloy and precision alloy.
