Inconel 690 /UNS N06690/W. Nr. 2.4642 U shape seamless pipe for Nuclear Power Industry
General introduction
Inconel 690 (UNS N06690/W. Nr. 2.4642) is a high-chromium nickel alloy with excellent resistance to many corrosive aqueous media and hightemperature atmospheres. In addition to its corrosion resistance, Inconel 690 has high strength, good metallurgical stability, and favorable fabrication characteristics.
The substantial chromium content gives the alloy outstanding resistance to oxidizing chemicals and to high-temperature oxidizing gases.
The high level of nickel imparts resistance to stresscorrosion cracking in chloride-containing environments as well as to sodium hydroxide solutions. The properties of Inconle 690 are useful for various applications involving nitric or nitric/hydrofluoric acid solutions. Examples are tail-gas reheaters used in nitric acid production and heating coils and tanks for nitric/hydrofluoric solutions used in pickling of stainless steels and reprocessing of nuclear fuels.
The alloy’s resistance to sulfur-containing gases makes it an attractive material for such applications as coal-gasification units, burners and ducts for processing sulfuric acid, furnaces for petrochemical processing, recuperators, incinerators, and glass vitrification equipment for radioactive waste disposal.
In various types of high-temperature water, alloy 690 displays low corrosion rates and excellent resistance to stress-corrosion cracking. Thus, alloy 690 is widely used for steam generator tubes, baffles, tubesheets, and hardware in nuclear power generation.
Chemical compostion
|
Element |
Content (%) |
|
Chromium, Cr |
27-31 |
|
Iron, Fe |
7-11 |
|
Silicon, Si |
0.5 max |
|
Manganese, Mn |
0.5 max |
|
Copper, Cu |
0.5 max |
|
Silicon, Si |
0.5 max |
|
Carbon, C |
0.05 max |
|
Sulfur, S |
0.015 max |
|
Nickel, Ni |
Balance |
Physical property
|
Properties |
Metric |
Imperial |
|
Density |
8.19 g/cm³ |
0.296 lb/in³ |
|
Melting point |
1343-1377°C |
2450-2510°F |
Applications
-
Duct work
-
High temperature burners
-
Furnaces
-
Petrochemical heaters
-
Nuclear power
Dimension
O.D.: 10-20mm
Wall thickness: 1-2mm
Length: 3-15 meter
Finish
Black or bright finish
